J7EF Gaze

Advanced Human-Computer Interaction

產品特點

  • AR 3D智慧眼鏡
  • 與Android手機或主機盒相容
  • 近眼顯示提供最真實的3D視覺體驗
  • 高解析度與寬視角顯示
  • 以九軸感測器進行移動偵測
  • 八百萬畫素相機經典演繹AR/MR應用
  • 飛時測距 (ToF: Time of Flight) 感測器支援精準測距
  • 眼球追蹤(Eye Tracking)自然直覺操作

自然的人機互動

Optic

Display Type

Si-OLED display

Resolution

FHD (1920 x 1080)

FOV

34 degree (120 inch at 5m)

Color Reproduction

24 bit-color

Display Input

Connector

USB Type-C (DisplayPort Alternate Mode)

Power

D3.0, USB Type-C (5V/1.9A)

Display Output

Interface

MIPI DSI, left & right channel

Resolution

1920 x 1080

Mechanical

133g ± 15g

45g ± 5g

Weight- Headset (exclude visor)

Weight- Interface Box (include cable)

Sensors

3 axis gyroscope

3 axis accelerator

3 axis magnetometer

Camera Sensor

ToF (Time of Flight) Sensor

Eye Tracking Sensor

Environmental

Operating Temperature

5°C- 35°C / 20%- 80% RH

Storage Temperature

-10°C- 60°C/ 20%- 80% RH

J7EF Gaze

pdf

J7EF Series Host Device List V1.3_20220329

Size : 168.72 kb
Hits : 781
Date added : 29 - 03 - 2022
Date modified : 29 - 03 - 2022
pdf

J7EF Gaze DM_20220304

Size : 1.99 mb
Hits : 834
Date added : 10 - 03 - 2022
Date modified : 10 - 03 - 2022
